The 111 Musiccenter, the 218 Power Amplifier, and the impressive BC150 speakers in the limited edition feature striking silver accents and warm wood elements that harmoniously blend with a case in a soft champagne tone.

限定版の 111 Musiccenter、218 Power Amplifier、印象的な BC150 スピーカーは、印象的なシルバーのアクセントと温かみのある木製の要素が特徴で、柔らかなシャンパン トーンのケースと調和しています。

The next level of sound is coming.

All will be revealed on October 9th.

An Evolutionary Design
Unveil on October 21st 10:00 am

THE FIRST Power amplifier

Equipped with a power of 330W at 8 Ohms, 660W at 4 Ohms, and 1320W at 2 Ohms, our High-Current Power Amplifier offers the possibility to effortlessly drive the most challenging acoustic speaker while offering the same elegance and refinement of Sound with highly sensitive loudspeaker systems (High Efficiency).

 How? We have managed to create an Amplifier capable of handling infinitesimal signals although hardly measurable (Sound Carpet) and at the same time signals of dynamic amplitude and speed “beyond” the audio band, making the system as conservative as possible in relation to the treatment of harmonics as well as their duration. The result? Timbral coherence, maintenance of harmonics with absolute rigor both through a complex acoustic speaker system and easy handling.

Technical Data

Nominal Output Power:

330 watts RMS @ 8 ohms

660 watts RMS @ 4 ohms

1320 watts RMS @ 2 ohms

A/B Class

Total Harmonic Distortion (THD):

 < 0,01 % from 5 Hz to 100 kHz

Analog Input:

2 x XLR > 47 kohms

2 x XLR bypass output

Signal to noise ratio:

 > 116 dB (A) @ nominal power

Gain:

32 dB for maximal out

Power consumption:

2,5 watts Standby, 40 watts @ idle, 2500 watts @ maximum output power

Speaker Output Impedance:

< 0.2 ohms from 10 Hz to 40 kHz (measured in 8 ohms)

Size in mm:

440 x 447 x 216 (WxDxH)

Frequency Response:

1.0 Hz – 300 kHz, ± 0,1 dB

Size in inches:

17,33 x 17,60 x 8,5 (WxDxH)

Slew Rate:

> 1300 V/µs

Net weight:

45 Kg

DC Output Voltage:

± 15 mV

Fuse ratings:

115 volts: 20A (T)

230 volts: 10A (T)

Factory selectable

THE DRIVER Pre amplifier

Having the function of regulating the amplitude of the signal coming from the source, seemingly a very simple task, the Pre Amplifier is in fact the most complex element of the Audio chain, determining the character as well as the sonic structure cascading to the entire system that follows it.

Decades of experience combined with the professional heritage acquired working closely with Sound Engineers as well as using absolute reference Studio Broadcast machines like EMT, STUDER, NAGRA PROFESSIONAL, AMPEX, OTARI, etc., have contributed to the achievement of a unique instrument, obtaining a Pre Amplifier that offers together with the musicality of a valve, all the precision of a solid-state, adding extension, speed, and “black background” appreciable only at a live event.



Technical Data

Line Gain:

Up to + 10 dB

Signal to noise ratio:

> 101 dB (A)

Analog Input Impedances:

4 x RCA line 47 kohms, from 5 Hz to 100 kHz

4 x XLR Line 47 kohms, from 5 Hz to 100 kHz

1 x optional future imput slot

Power consumption:

5 – 60 watts depending on working conditions

Line Output impedances:

RCA 30 ohms

XLR 600 ohms

REC OUT < 100 ohms

Remote control:

full functions

Frequency Response:

 1 Hz – 300 kHz, ± 0,2 dB

Size in mm:

440 x 335 x 136 (WxDxH)

Rise Time:

 < 0.8 µs

Size in inches:

17,33 x 13,19 x 5,35 (WxDxH)

Slew Rate:

> 34 V/µs

Net weight:

15 kg

Total Harmonic Distortion (THD):

< 0,001 % from 10 Hz to 100 kHz max out + 18 dBu

Fuse ratings:

115 volts: 20A (T)

230 volts: 10A (T)

Factory selectable

Crosstalk:

< – 90 dB from 20Hz to 20kHz

Introducing the Coda XLR

The Coda XLR is engineered to deliver top-tier audio performance, featuring premium-grade components and cutting-edge technology. Both the male and female connectors are crafted with silver for superior conductivity and signal transfer.

Designed for audiophiles and professionals who demand nothing but the best, the Coda XLR took over two years to perfect, as incorporating silver—a soft and malleable material—into the connectors posed unique challenges.

The housing is constructed from brass, providing excellent EMI/RF noise rejection and vibration damping to ensure an ultra-clean signal. With the increasing use of processors and switching power supplies in modern audio systems, isolating noise has never been more important.

Additionally, the housing features dual strain relief screws, offering extra protection to the cable and connectors, safeguarding them from the wear and tear caused by constant plugging and unplugging.

Coda XLR のご紹介

Coda XLR は、最高級のコンポーネントと最先端のテクノロジーを採用し、最高レベルのオーディオ パフォーマンスを実現するように設計されています。オスとメスの両方のコネクタは銀で作られており、優れた導電性と信号転送を実現しています。

最高のものだけを求めるオーディオ愛好家や専門家向けに設計された Coda XLR は、柔らかくて柔軟性のある素材である銀をコネクタに組み込むという独特の課題があったため、完成までに 2 年以上かかりました。

ハウジングは真鍮製で、優れた EMI/RF ノイズ除去と振動減衰を提供し、非常にクリーンな信号を保証します。現代のオーディオ システムではプロセッサとスイッチング電源の使用が増えているため、ノイズの分離がこれまで以上に重要になっています。

さらに、ハウジングには二重のストレイン リリーフ ネジが付いており、ケーブルとコネクタをさらに保護し、頻繁な抜き差しによる摩耗から保護します。

Diva Utopia

3-WAY ACTIVE WIRELESS LOUDSPEAKER

DIVA UTOPIA combines the best of Focal Acoustics and Naim Electronics. This active bass-reflex speaker offers high-quality sound, the latest wireless technologies, and extensive connectivity for exceptional listening experiences. Whether it’s music, movies, or video games, it revolutionises home listening and frees you from all constraints. With DIVA UTOPIA and its unique design, simply plug in, connect, and enjoy the pure sound of Focal.

EASE OF USE, HIGH RESOLUTION

DIVA UTOPIA is easy to install and use, with no wires connecting the speakers. Thanks to Ultra Wideband (UWB) technology, the sound quality is exceptional, surpassing CD standards by delivering studio-grade sound at 192kHz/24bits. For added convenience, the speaker can be controlled via the Focal & Naim app, a remote control, and voice assistants such as Google Assistant and Siri.

A DESIGN ICON

A true acoustic masterpiece, DIVA UTOPIA combines sophisticated materials with an open design. The Utopia codes are visually represented by the tweeter’s dual red and black grille and the ‘ribbon’ surrounding the tweeter in a yin-yang formation, symbolising the harmony of craftsmanship and technology. This creates a distinctive and symbolic “signature watch.”

TECHNOLOGICAL EXCELLENCE

Focal loudspeakers are designed with a beryllium tweeter, a mid-bass speaker driver, and four side-mounted woofers to deliver extremely precise sound. They also come with powerful Naim amplification and a high-quality streaming platform, ensuring the highest fidelity reproduction that captures every detail of the music.

UNIQUE PANELLING

The side panels are designed to be both floating and removable, adding a versatile element to the speaker. They are crafted from felt, an OEKO-TEX®-certified material known for its durability and aesthetic appeal. These panels feature refined lines and include a signature opening in the front to elegantly house the backlit Focal logo. Positioned behind the panels, the bass speakers are subtly integrated on the sides, enhancing the overall sound diffusion.

• Product type : 3-way bass-reflex active
• Membrane :
  ‘W’ 61/2″ (16.5cm)
• Woofer : 4 x ‘W’ 61/2″ (16.5cm) push-push configuration
• Medium : ‘W’ 61/2″ (16.5cm) with TMD surround and NIC motor
• Tweeter :
  IAL2 15/8″ (27mm) pure beryllium ‘M’-shaped inverted dome
• Response at – 6dB (Low frequency point) : 24 Hz
• Frequency response (+/- 3dB) :
  30 Hz-40 kHz
• Recommended amplifier power : Per speaker, LF: 250W Class AB MF: 75W Class AB HF: 75W Class AB
• Sensivity : (per pair) 116 dB SPL (@ 1 m)

• Inputs :
  Primary loudspeaker:
  – HDMI eARC, CEC
  – TOSLINK Optical
  – RCA analogue
  – Type A USB 2.0
  – RJ45 Ethernet

  Secondary loudspeaker:
  – RJ45 Speaker Link

• Audio Format :
  – WAV, FLAC and AIFF – up to 24bits/384kHz
  – ALAC (Apple Lossless Audio Codec) – up to 24bits/384kHz
  – MP3 – up to 48kHz/ 320kbits (16bits)
  – AAC – up to 48kHz/320kbits (16bits)
  – OGG and AAC – up to 48kHz (16bits)
  – DSD64 and DSD128
  – Bluetooth® – aptX™ Adaptive, SBC, AAC
  – Note: handles smooth, gapless playback on all formats

KKBOX for U2, U2 Mini, P1 Mini, T3, D3

QQMusic for all LUMIN Players

Android App v7 and iOS App v10 also out now

Aesthetic Modifications

• Customer can choose any Paint color
• Customer can choose “Black” or “Clear” Hardware color
  • Clear Hardware will reveal more of the custom machine lines and look more jewel like
  • Some Hardware pieces will always be either Black or Clear
• Main In connector plate
  • Prismatic finish

Gantry

• Alignment block plate (x2)
  • Prismatic finish
  • Deep laser engraving with the number indicators the high point (reverse boss)
• Light bar cross-brace
  • Prismatic finish
• Gantry blades
  • Prismatic finish with deep “global radial” grooves

Upper Modules

• Cable grip hardware
  • Stainless steel in Black Nickel finish (always black finish to match cable color)
• Tweeter metal cross-brace
  • Prismatic finish
• Upper module bolt locking hardware (always black finish)
  • Stainless Steel

Woofer Enclosure

• Rear crossover cover
  • “Honeycomb” carbon fiber insert in middle (laser engraving TBD)
• Port cover / ring
  • “Honeycomb” carbon fiber insert on cover with prismatic finish on edges
  • Prismatic finish on ring
• Resistor Plate
  • “Honeycomb” carbon fiber behind the resistor heatsinks and hardware

Performance $3500
Signature model $5000
Cryogen model $7000

InfigoAudio introduces their brand new streamer model, the IS-1.

The streamer is the culmination of multiple, unique digital source product developments in the classic Infigo style designed enclosure.

There are three versions: Performance, Signature and Cryogen.

Product highlights:

USB audio optimized connection to a DAC for highest possible sample rates of digital music

Built in ultra low noise linear power supply creates very low noise floor, creating a very black music background

Network attached internal local storage of music (up to 4TB) to play music local direct to DAC

Fiber optic isolation of network connection to block network noise creates a separation between the ‘dirty’ network and clean audio chain

Ultra low jitter re-clocking of network audio packets (Signature and Cryogen version) eliminates the need for audiophile grade network gear

Built in local webpage with all control functions easily accessible via a browser in the network

Four different modes of operation to be compatible with 99% of music players in the market: Audirvana, uPnP, Roon, HQPlayer

Powerful Intel Quad Core CPU with one high speed core fully dedicated to music gives optimum sound quality for all modes of operation

Cryogenically treated internal cable model available (Cryogen version)

The new Infigo Audio Streamer IS-1, like all other Infigo products, has a clear top panel cover that shows the blue LED illuminated internals.

The blue front panel LEDs can be dimmed via the built in local webpage, which also gives a status information overview panel and a settings menu to change the mode of operation.

The internal local music storage presents itself on the network as a network drive and is compatible with most Windows, Mac and Linux systems.

The streamer can operate as an Audirvana Server, Roon Endpoint, HQPlayer Network Audio Adapter or Universal Plug and Play (UPnP) music endpoint, which covers 99% of music players in the market.

All of these modes of operation run exclusively on a dedicated high speed processor core to make sure nothing interrupts the precious audio process while playing. This streamer will get the best out of any USB DAC.

The gigabit fiber optic isolated network connection eliminates network noise and jitter. The optic converters in the unit are powerful enough to bridge a fiber cable more than 10 miles long.

The streamer comes standard with an armored fiber optic cable of 3 meters but can be supplied with different lengths on request.

The base model, Performance, lists at $3500, the Signature model lists at $5000 and the Cryogen model $7000

InfigoAudio は、まったく新しいストリーマー モデル、IS-1 を発表しました。

ストリーマーは、クラシックな Infigo スタイル設計の筐体に複数のユニークなデジタル ソース製品開発の集大成です。

パフォーマンス、シグネチャー、クライオジェンの 3 つのバージョンがあります。

製品のハイライト:

USB オーディオに最適化された DAC への接続により、デジタル音楽の最高サンプル レートを実現

超低ノイズのリニア電源を内蔵し、ノイズ フロアを非常に低く抑えて、非常にブラックな音楽の背景を作成

ネットワーク接続された音楽の内部ローカル ストレージ (最大 4TB) により、ローカルで DAC に直接音楽を再生

ネットワーク接続の光ファイバー分離により、ネットワーク ノイズをブロックし、「ダーティ」なネットワークとクリーンなオーディオ チェーンを分離

ネットワーク オーディオ パケットの超低ジッター リクロッキング (Signature および Cryogen バージョン) により、オーディオ愛好家向けのネットワーク ギアが不要

ローカル Web ページを内蔵し、ネットワーク内のブラウザーからすべてのコントロール機能に簡単にアクセス可能

4 つの異なる動作モードにより、市場の音楽プレーヤーの 99% と互換性があります: Audirvana、uPnP、Roon、HQPlayer

強力な Intel Quad Core CPU と音楽専用の高速コア 1 つにより、すべての動作モードで最適な音質を実現

極低温処理された内部ケーブル モデルも利用可能 (Cryogen) バージョン)

新しい Infigo Audio Streamer IS-1 は、他のすべての Infigo 製品と同様に、青色 LED で照らされた内部部品が見える透明なトップ パネル カバーを備えています。

青色のフロント パネル LED は、内蔵のローカル Web ページから暗くすることができます。また、ステータス情報の概要パネルと、動作モードを変更するための設定メニューも表示されます。

内部のローカル ミュージック ストレージは、ネットワーク上でネットワーク ドライブとして表示され、ほとんどの Windows、Mac、Linux システムと互換性があります。

ストリーマーは、Audirvana サーバー、Roon エンドポイント、HQPlayer ネットワーク オーディオ アダプター、または市場の音楽プレーヤーの 99% をカバーするユニバーサル プラグ アンド プレイ (UPnP) ミュージック エンドポイントとして動作できます。

これらの動作モードはすべて、専用の高速プロセッサ コアでのみ実行されるため、再生中に貴重なオーディオ処理が中断されることはありません。このストリーマーは、あらゆる USB DAC を最大限に活用できます。

ギガビット光ファイバー分離ネットワーク接続により、ネットワーク ノイズとジッターが排除されます。 ユニット内の光コンバーターは、10 マイルを超える長さの光ファイバー ケーブルをブリッジできるほど強力です。

ストリーマーには 3 メートルの装甲光ファイバー ケーブルが標準で付属していますが、リクエストに応じて異なる長さのケーブルも提供できます。

基本モデルの Performance は 3,500 ドル、Signature モデルは 5,000 ドル、Cryogen モデルは 7,000 ドルです。

We are proud to announce the introduciton of the upgrade option for the 701 mono and 711 stereo amplifier.

Following our credo: do not add anything, do not omit anything, we challenged ourselves by asking the question: “Can we add less and omit less compared to what we have already achieved”? Before we decided to implement an all new and innovative amplification topology for our new 717 power amplifier our engineers evaluated how far they can push the performance of the 701 and 711s amplifier structure. Some of the results from this analysis now find their way into a new upgrade option in the 701+ and the 711+.

The new, ultra linear feedback network along with the improved thermal design of the gain stages have boosted the voltage amplification module to both improve the phase response of the amplifier as well as its overload stability. The upgrades to 701+ and 711+ preserve all the sonic virtues of the 701 and 711 like their effortless separation of instruments even in the most complex passages, its bass dynamics and ravishing tonal colour, but it will add more refinement and delicacy to the musical representation bringing you even closer to the artist’s true performance.

All existing 701s and 711s can be upgraded to the 701+ or 711+. Due to their modular design the 701 and 711 amplifiers are upgradable to the + version by replacing the two output amplifier modules with + upgraded modules. Please contact your dealer to check if the upgrade can be done at a local service-center or if the unit needs to be returned to the factory.

Upgrade price: CHF 15’000 (incl. VAT 8.1%) per amplifier
Available from Q4/2024

701 モノラルおよび 711 ステレオ アンプのアップグレード オプションの導入を発表できることを誇りに思います。

当社の信条である「何も追加せず、何も省略しない」に従い、私たちは「これまで達成してきたものよりも追加や省略を少なくできるか」という問いかけに挑戦しました。新しい 717 パワー アンプにまったく新しい革新的な増幅トポロジーを実装することを決定する前に、当社のエンジニアは 701 および 711s アンプ構造のパフォーマンスをどこまで向上できるかを評価しました。この分析の結果の一部は、現在、701+ および 711+ の新しいアップグレード オプションに反映されています。

新しい超線形フィードバック ネットワークとゲイン ステージの改良された熱設計により、電圧増幅モジュールが強化され、アンプの位相応答と過負荷安定性の両方が向上しました。 701+ および 711+ へのアップグレードでは、最も複雑なパッセージでも楽器を楽々と分離できること、低音のダイナミクス、魅惑的な音色など、701 および 711 の音響的長所をすべて維持しながら、音楽表現にさらなる洗練と繊細さを加え、アーティストの真のパフォーマンスにさらに近づくことができます。

既存の 701 および 711 はすべて、701+ または 711+ にアップグレードできます。モジュール設計のため、701 および 711 アンプは、2 つの出力アンプ モジュールを + アップグレード モジュールに交換することで + バージョンにアップグレードできます。アップグレードを地元のサービス センターで実行できるか、ユニットを工場に返却する必要があるかを確認するには、販売店にお問い合わせください。

アップグレード価格: アンプ 1 台あたり CHF 15,000 (VAT 8.1% を含む)
2024 年第 4 四半期から利用可能

Luxman’s first 100th anniversary model

Headphone amplifier P-100 CENTENNIAL
¥990,000 (tax included)

Luxman will release the headphone amplifier P-100 CENTENNIAL in November 2024 as the first commemorative model for the 100th anniversary of its founding.

In 2002, the P-1 was developed as a new genre that embodied the product idea of ​​a power amplifier dedicated to headphones, repurposing the unique ODNF technology developed as an amplification circuit for speaker driving power amplifiers. At the time, the P-1 was launched in the market for full-scale headphone listeners, which was not as large as it is today, and it quickly attracted the attention of many high-end users, and its unique sound quality was recognized as a reference for headphone builders and recording studio monitors. After that, in 2012, the P-700u was the first to fully balance the circuit ahead of many other companies. As a way to improve the unique connection situation of headphones, where the signal ground is shared between the left and right channels, many users now enjoy the high performance of balanced connections, from portable to stationary environments.

And now it has been 22 years since the introduction of the P-1. The latest headphone amplifier, the 7th generation P-100 CENTENNIAL, is an amplifier product that drives all kinds of headphones in every direction, and is released as a flagship model commemorating the 100th anniversary of the company’s founding, generously incorporating the best circuits and materials that Luxman can currently imagine.

At its heart is the unique amplification feedback circuit LIFES, which Luxman developed as a core technology that should be installed in its product lineup after the 100th anniversary. It achieves a generous output of rated 4W+4W (unbalanced output 8Ω load) and 8W+8W (balanced output 16Ω load), and has achieved the same rich sound field space, delicate expressiveness, and magnificent sound full of energy as the flagship power amplifier model M-10X. In order to support high sound quality and high power, it is equipped with a large-capacity high-inertia power supply with a completely independent left and right configuration from the power transformer to the regulator and block capacitor.

In addition, multiple output modes such as parallel, BTL, and ground independence, which combine the four built-in amplifier circuits, are available to select from, assuming connection to high-end headphones with various characteristics from all over the world. In addition, as a special mode, two P-100 CENTENNIALs are used to operate in mono, and an ultimate parallel BTL balanced output setting using a total of eight amplifier circuits is also available. It is also expandable so that it can fully demonstrate its capabilities in combination with headphones with unknown characteristics that will be released in the future.
In addition to the conventional functions, utilities for achieving comfortable listening include the adoption of the high-purity electronically controlled attenuator LECUA-EX with 200 stages in 0.5 dB steps, consisting of a combination of a volume knob with a smooth and moderate weight and a rotary encoder, a large 3-digit 7-segment LED, and a VOLUME LIMIT function to protect your ears from excessive volume.
As an exterior suitable for a flagship, it is equipped with a high-rigidity housing and an extremely thick bottom steel plate that have been enlarged to support a large amount of material, an oversized bonnet with a hairline finish on three sides, and a “CENTENNIAL” nameplate representing the 100th anniversary. The P-100 CENTENNIAL is an anniversary model from Luxman, which is celebrating its 100th anniversary soon, dedicated to all headphone lovers who aim for the pinnacle of direct listening, and it delivers overwhelming drivability and musicality.

■Features

• A fully balanced headphone amplifier with 4 amplifier circuits
• A wide range of output terminals compatible with various headphone plugs (unbalanced Φ6.3mm, balanced Φ4.4mm, balanced XLR-4P, balanced XLR-3P*)
• Dedicated terminal for parallel BTL balanced output mode using two units
• A total of 4 output configurations to choose from according to the desired performance and sound quality (see the “Output Configuration” table below)
• 3 inputs (unbalanced RCA, balanced XLR) that can connect multiple source devices ×2) and through output (unbalanced RCA) function

-Precise volume adjustment with a rotary encoder with 200 levels in 0.5dB steps from 0 to -99.5dB

-Large 7-segment LED for 3-digit volume display with excellent visibility

-Two types of output mode switching available when using balanced output terminals (BAL: BTL balanced / G-DIV [GROUND DIVIDE]: Parallel unbalanced with ground separated for LR)

-Three-level sensitivity switching (0, -6, -12dB) and LR balance adjustment (0.5dB steps, LR 0 to -12dB) without increasing unnecessary contacts by applying the circuit of the volume control mechanism LECUA, and volume mute function

-VOLUME to set the upper limit of the volume to protect your ears from excessive volume LIMIT function (6 levels: OFF, -10, -20, -30, -40, -50dB)

• A luxurious parallel BTL balanced output mode is available, consisting of a total of 8 amplifier circuits using two P-100s (see the connection image below)

■ Electrical circuit

• Equipped with four Luxman’s latest amplification feedback engine LIFES1.0
• Rated output of 4W+4W (unbalanced output 8Ω load) and 8W+8W (balanced output 16Ω load) that linearly follows the load resistance of various headphones. Maximum output is 20W+20W (balanced output 8Ω load)
• Within the rated output, one output element amplifies all musical waveforms, achieving pure class A operation without switching distortion (unbalanced output 32Ω load)
• The volume control mechanism uses the latest solid-state drive that does not lose musical details even at low volume The LECUA-EX combines a state-type high-purity electronically controlled attenuator with a heavy rotating mechanism to provide a high-quality feel.
• The power supply section is equipped with two large-capacity OI-type transformers for the amplifier circuit, and a transformer for the peripheral circuits for relay switching and LED indicators.
• The power stage uses a large-capacity high-inertia power supply circuit with four 10,000μF block capacitors and four 3,300μF block capacitors for the driver stage, with left and right independent configurations.
• Large, low-resistance speaker relays are connected in parallel to thoroughly reduce the impedance of the output line that drives the headphones.
• Theory-backed construction, such as Beeline construction, which configures the signal flow to be the most rational and shortest wiring path, and round pattern wiring that achieves smooth, stress-free signal transmission. A wealth of carefully crafted technology

■Design, mechanism, and accessories

• The glossy chrome-plated “CENTENNIAL” nameplate is only fitted to the 100th anniversary model
• The case size has been significantly increased from the previous model (P-750uII) (panel height 80 → 120mm) to accommodate the amount of material required to achieve overwhelming flagship performance
• The 6mm-thick three-sided aluminum increases the rigidity of the case, and the fine hairline finish and the powerful face that protrudes from the front panel create a luxurious feel for a top-end product Oversized bonnet
• Extra thick 4.1mm (2.9+1.2mm) steel bottom chassis that increases ground mass and also acts as a heat sink for the power block
• Gradient cast iron legs that protect delicate micro-level music signals from unnecessary vibrations
• Gold-plated AC inlet with a different mounting direction that allows the entire terminal to support the weight of the cable
• JPA-15000 power cable (with polarity mark) uses 3.5mm² high-purity OFC wire with a non-twisted structure and a gold-plated plug

ラックスマン創業100 周年記念モデル第1 弾
ヘッドフォンアンプ P-100 CENTENNIAL
¥990,000（税込）

ラックスマンは、創業100周年の記念モデル第1弾として、ヘッドフォンアンプ P-100 CENTENNIALを2024年11月に発売いたします。
2002年、スピーカー駆動用パワーアンプの増幅回路として開発された独自のODNFテクノロジーを転用する新たなジャンルとして、ヘッドフォン専用パワーアンプという商品アイデアを具現化したのがP-1でした。当時、現在ほど大きくはなかった本格的なヘッドフォンリスナー向けの市場に投入されたP-1は、またたく間に多くのハイエンドユーザーに注目され、ヘッドフォンビルダーや録音スタジオのモニター用リファレンスとして唯一無二の音質が認められることとなりました。その後、2012年にはP-700uで多くの他社に先駆けて回路をフルバランス化。信号グラウンドが左右チャンネルで共通化されているヘッドフォン独自の接続事情を改善する方法として、現在ではポータブルから据え置きの環境まで、多くのユーザーがバランス接続の高性能を楽しんでいます。
そしてP-1の登場から22年。第7世代目となる最新ヘッドフォンアンプ P-100 CENTENNIALは、あらゆるヘッドフォンを縦横無尽にドライブするアンプ製品として、現在ラックスマンが考え得る最高の回路と物量を惜しげなく注ぎ込んだ創業100周年記念のフラグシップモデルとして登場します。
心臓部には、ラックスマンが100周年以降の製品ラインアップにも搭載すべき基幹技術として開発した独自の増幅帰還回路LIFESを搭載。定格4W+4W(アンバランス出力8Ω負荷)、8W+8W(バランス出力16Ω負荷)の余裕ある出力を実現し、パワーアンプのフラグシップモデルM-10X同様の豊かな音場空間と繊細な表現力、そしてエネルギー感あふれる壮大なサウンドを獲得しました。そして高音質とハイパワーをサポートするため、新たに電源トランスからレギュレーター、ブロックコンデンサーまでを完全に左右独立構成した大容量ハイイナーシャ電源を搭載しています。
また、世界中のさまざまな特性を持つハイエンドヘッドフォンとの接続を想定し、内蔵する4アンプ回路を組み合わせたパラレル、BTL、グラウンド独立など、複数の出力モードを選択可能としました。さらにスペシャルなモードとして、P-100 CENTENNIALをモノラル動作させるために2台使用し、合計8アンプ回路を使用した究極のパラレルBTLバランス出力設定も用意。今後登場する未知の特質を持ったヘッドフォンとの組み合わせにおいても充分に能力を発揮できる拡張性も準備しています。
快適なリスニングを実現するためのユーティリティとしては、従来機能に加え、スムーズで適度な重量感を持ったボリュームノブとロータリーエンコーダーの組み合わせで構成された、0.5dBステップ200段階の高純度電子制御アッテネーターLECUA-EXの採用を始め、3桁の大型７セグメントLEDの搭載、そして過大な音量から耳を保護するためのVOLUME LIMIT機能なども搭載しています。
フラグシップに相応しいエクステリアとして、多くの物量を支えるためにサイズアップされた高剛性筐体と極厚のボトム鋼板、そして3面ヘアライン仕上げのオーバーサイズボンネットと100周年を表す「CENTENNIAL」銘板も装着。P-100 CENTENNIALは、創業100周年を間近に控えたラックスマンから、ダイレクトリスニングの頂を目指す すべてのヘッドフォンラヴァーに贈る、圧倒的なドライバビリティとミュージカリティを突き詰めたアニバーサリーモデルです。

■機能

・4アンプ回路を搭載したフルバランス構成のヘッドフォン専用アンプ

・さまざまなヘッドフォンプラグに対応する豊富な出力端子(アンバランスΦ6.3mm、バランスΦ4.4mm、バランスXLR-4P、バランスXLR-3P※)
※ 本機を2台使用するパラレルBTLバランス出力モード専用端子
・求める性能や音質に合わせ選択可能な全4種の出力構成(下記「出力構成」表をご参照ください)

・複数のソース機器を接続可能な3系統の入力(アンバランスRCA、バランスXLR ×2)とスルー出力(アンバランスRCA)機能

・0～-99.5dBまで0.5dBステップ200段階のロータリーエンコーダーによる細やかな音量調節

・視認性に優れる3桁の音量表示用大型7セグメントLED

・バランス出力端子使用時に選択可能な2種類の出力モード切替(BAL:BTLバランス／G-DIV[GROUND DIVIDE]:グラウンドをLR独立させたパラレル・アンバランス)

・音量調節機構LECUAの回路を応用することで無用な接点を増加させない3段階の感度切替(0、-6、-12dB)とLRバランス調節(0.5dBステップ、LR0～-12dB)、音量ミュート機能

・過大な音量から耳を保護するためにボリュームの上限を設定するVOLUME LIMIT機能(OFF、-10、-20、-30、-40、-50dBの6段階)

・P-100を2台使用して全8アンプ回路で構成する贅沢なパラレルBTLバランス出力モードを用意(下記接続イメージをご参照ください)

■電気回路

・ラックスマン独自の最新・増幅帰還エンジンLIFES1.0を4基搭載

・さまざまヘッドフォンの負荷抵抗にリニアに追随する4W+4W(アンバランス出力8Ω負荷)、8W+8W(バランス出力16Ω負荷)の定格出力
最大出力は20W+20W(バランス出力8Ω負荷)を実現

・定格出力内ではひとつの出力素子で音楽波形のすべてを増幅し、スイッチング歪の発生しない純A級動作を実現(アンバランス出力32Ω負荷)
・音量調節機構には、小音量時にも音楽のディテールを失わない最新型ソリッドステートタイプの高純度電子制御アッテネーターと重量回転メカを組み合わせ、上質な操作感を提供するLECUA-EXを採用

・電源部にはアンプ回路用にLR独立の大容量OI型トランス×2と、リレー切替やLEDインジケーター類のための周辺回路用トランスを独立搭載

・パワー段には10,000μF×4本、ドライバー段には3,300μF×4本のブロックコンデンサーをLR独立構成で搭載した大容量ハイイナーシャ電源回路を採用

・低抵抗値のスピーカー用大型リレーを並列接続し、ヘッドフォンを駆動する出力ラインを徹底的に低インピーダンス化

・信号の流れが最も合理的かつ短い配線経路となるよう構成するビーラインコンストラクションや、スムーズでストレスのない信号伝送を実現するラウンドパターン配線など、理論に裏打ちされた こだわりの技術を豊富に投入

■デザイン、機構・付属品

・創業100周年記念モデルにのみ装着される光沢クロムメッキ仕上げの「CENTENNIAL」銘板

・圧倒的なフラグシップ性能を実現する物量を搭載するため、筐体サイズを従来モデル(P-750uII)から大幅拡大(パネル高80→120mm)

・筐体の剛性を高め、精細なヘアライン加工とフロントパネルから張り出した迫力のフェイスがトップエンド製品のラグジュアリー感を演出する、6mm厚の3面アルミ製オーバーサイズボンネット

・グラウンドマスの増大やパワーブロックの放熱器も兼ねた極厚4.1mm(2.9+1.2mm)の鋼板ボトムシャーシ

・微小レベルのデリケートな音楽信号を不要な振動から守るグラデーション鋳鉄製レッグ

・装着方向を変更し端子全体でケーブルの重量をサポート可能とした金メッキ仕上げのACインレット

・ノンツイスト構造の3.5mm²高純度OFC線と金メッキ仕上げのプラグを採用した電源ケーブルJPA-15000(極性マーク付き)

119
modern and compact bookshelf loudspeaker

150 high-performance yet compact 3-way loudspeaker

Selekt DSM: Classic Hub

Selekt DSM: Classic Hub

Key features

Aluminium construction with acrylic fascia

Cut-glass control dial

Six programmable machined stainless-steel ‘smart’ buttons

Wide range of inputs accept virtually any source

High-performance MM/MC/Line-In Analogue Phono Stage

Powered by Utopik – Linn’s best power supply design ever

Browse your digital music library, stream online music and video, and experience movie and game soundtracks – all rendered in exceptional detail by a Selekt DSM: Classic Hub.

Classic Hub features a broad range of digital and analogue inputs, in order to receive, process and expertly deliver audio from any source imaginable. The high-performance, integrated, analogue-to-digital conversion stage accepts anything from turntables to CD players, and a host of digital connections allows connection from video streaming devices, games consoles and Blu-ray players – ensuring you get the best possible sound from anything you connect.

Zero loss and perfect phase

Selekt DSM: Classic Hub can easily be upgraded with multiple amplifiers and DAC modules to bring your Selekt System up to peak performance. A Selekt System configured in this way is the perfect choice for those seeking an all-Linn, superior-performance solution from the outset – incorporating the astonishing sonic benefits of our Exakt technology.

Featuring Linn’s industry-leading DS technology – and with up to 24bit/384kHz and DSD256 streaming capability – every last musical detail is preserved, in an elegantly simple system with perfect phase and zero crossover distortion.

デジタル音楽ライブラリを閲覧したり、オンライン音楽やビデオをストリーミングしたり、映画やゲームのサウンドトラックを体験したりできます。これらはすべて、Selekt DSM: Classic Hub によって非常に詳細にレンダリングされます。

Classic Hub は、さまざまなデジタルおよびアナログ入力を備えており、考えられるあらゆるソースからオーディオを受信し、処理し、巧みに配信します。高性能の統合型アナログ-デジタル変換ステージは、ターンテーブルから CD プレーヤーまであらゆるものを受け入れ、多数のデジタル接続により、ビデオストリーミングデバイス、ゲームコンソール、Blu-ray プレーヤーからの接続が可能で、接続するものすべてから可能な限り最高のサウンドを得ることができます。

ゼロ損失と完璧な位相

Selekt DSM: Classic Hub は、複数のアンプと DAC モジュールで簡単にアップグレードでき、Selekt システムを最高のパフォーマンスに引き上げることができます。このように構成された Selekt システムは、最初からすべて Linn の優れたパフォーマンス ソリューションを求めている方にとって最適な選択であり、Exakt テクノロジーの驚くべき音響的利点が組み込まれています。

業界をリードする Linn の DS テクノロジーを搭載し、最大 24 ビット/384 kHz および DSD256 ストリーミング機能を備え、完璧な位相とクロスオーバー歪みのないエレガントでシンプルなシステムで、音楽の細部まですべて保存されます。

150

Key features

Superior linear performance

Linn logo tweeter guard

Premium drive units

High-quality, lower-order passive crossover

Down-ported design delivers excellent omnidirectional bass performance

Crossover easily and quickly bypassed for Exakt operation

150 is a high-performance yet compact 3-way loudspeaker. This all-new, passive speaker model is energetic, conspicuously refined – and loads of fun!

150 possesses dual downwards-firing ports at the base of its cabinet. This produces tremendous omnidirectional bass performance and minimises undesirable interaction between the speaker and the walls of your room.

The internal passive crossover can also be bypassed in a matter of minutes. This enables upgrade to the ultimate Selekt System; featuring our industry-leading Exakt technology with expanded amplification, DAC modules, and Exakt digital crossover all neatly mounted within your Selekt DSM: Classic Hub.

150 は高性能でありながらコンパクトな 3 ウェイ ラウドスピーカーです。このまったく新しいパッシブ スピーカー モデルは、エネルギッシュで、非常に洗練されており、とても楽しいです。

150 は、キャビネットの底部に下向きのデュアル ポートを備えています。これにより、全方向の優れた低音パフォーマンスが実現し、スピーカーと部屋の壁の間の望ましくない相互作用が最小限に抑えられます。

内部のパッシブ クロスオーバーも、わずか数分でバイパスできます。これにより、業界をリードする Exakt テクノロジーと拡張増幅、DAC モジュール、Exakt デジタル クロスオーバーがすべて Selekt DSM: Classic Hub 内にきちんと取り付けられた究極の Selekt システムにアップグレードできます。

119

Key features

Exceptional linear performance

Linn logo tweeter guard

Premium drive units

High-quality, lower-order passive crossover

Rear-ported design delivers excellent bass performance

Crossover easily and quickly bypassed for Exakt operation

119 is a modern and compact bookshelf loudspeaker. It delivers a superbly engaging performance that belies its size – even when positioned close to a boundary wall.

As part of a Selekt System, 119 can have its rear port bypassed and a digital bass augmentation filter applied to produce even faster, tighter low-end performance. Its passive crossover can easily be bypassed too, enabling upgrade of your system to Exakt performance level.

119 performs adeptly whether mounted on a stand or placed on a shelf or furniture.

119 はモダンでコンパクトなブックシェルフ スピーカーです。境界壁の近くに設置しても、そのサイズからは想像できないほど魅力的なパフォーマンスを発揮します。

119 は、スタンドに取り付けても、棚や家具に置いても、優れたパフォーマンスを発揮します。

Selekt システムの一部として、119 はリア ポートをバイパスし、デジタル ベース オーグメンテーション フィルターを適用して、さらに高速でタイトな低音パフォーマンスを実現できます。パッシブ クロスオーバーも簡単にバイパスできるため、システムを Exakt パフォーマンス レベルにアップグレードできます。

Precision Engineering and Elegant Design for Unmatched Musical Performance

Børresen is proud to announce the official launch of the Børresen C1, a stand-mounted loudspeaker that blends cutting-edge technology with exquisite design. Engineered to deliver extraordinary musical detail, clarity, and depth, the C1 offers exceptional performance within high-end loudspeakers. With its innovative materials and precision-crafted components, the C1 delivers a remarkable and immersive listening experience.

Bass/Midrange Drivers: Børresen DCC5 NEO

At the core of the C1’s performance is the Børresen 5-inch CC Neo bass/midrange driver, meticulously crafted to deliver superior clarity and dynamics.

The Membrane

The Børresen X1 continues the legacy of the X Series and features the same remarkable technologies that characterize all the X series speakers, embodying the brand’s philosophy of precision engineering and audio innovation. At the heart of the Børresen X1 is a blend of cutting-edge technologies, adopted from the highly acclaimed M, O and Z loudspeaker series, and carefully integrated into the new X1 speakers to deliver an authentic and absolute natural musical experience. The speaker’s compact size belies its exceptional performance, as it houses the exclusive Børresen X-Series ribbon tweeter and a 4.5-inch Børresen X-Series speaker driver for a rich, detailed, and dynamic soundstage.

The Magnetic Motor System

The C1 features a sophisticated magnetic motor system with double copper caps on the pole rings. This design, adapted from higher-end Børresen drivers, minimizes electromagnetic resonance and lowers inductance, easing the load on the amplifier.

The Børresen Ribbon Tweeter: Speed and Precision

The C1 is equipped with Børresen’s renowned RP94 ribbon tweeter, a signature feature of the Børresen brand. With a remarkable efficiency of 94 dB and an ultra-light moving mass of just 0.01 grams, this closed ribbon tweeter is capable of incredible speed and responsiveness. Operating from 2.5 kHz and above, it captures the finest sonic details with precision and is robust enough to handle high transient peaks without distortion. This level of detail and clarity allows listeners to experience music with a level of subtlety and refinement rarely achieved.

Crossover

The new Børresen C1 loudspeakers is based on serial crossover networks, which provide the same phase-locked electric current flow to transducers in the filtering region. Although this crossover topology is significantly more difficult to implement, by diverting the out-of-band currents it creates a much more coherent filtering system.

Structural Robustness: Designed for Acoustic Excellence

The Børresen C1 speaker enclosures are constructed from internally reinforced wood composite material, designed to minimize sound distortion, standing waves, and external resonances. This material, combined with 1mm-thick carbon fiber panels applied to the sides, significantly increases the rigidity of the enclosure. Glossy white/black side stripes laid on top of the thick carbon layers allow this material to work at its very best, and greatly contribute to the speaker’s unique aesthetic.

C1 Loudspeaker Stand: Perfect Synergy between Speaker and Stand

The C1 loudspeaker stands are designed to support the Børresen C1 speakers in the best possible way by placing the speakers in the correct height and angle. The stands are made of the same robust wood composite material as the cabinets, creating the perfect synergy between speakers and stands. As the stands are without iron components any magnetically interference into the loudspeakers crossovers is avoided. The stands are equipped with Ansuz Darkz S2t Resonance Control devices, further reducing vibrations and improving sound quality. The stands can also be upgraded with additional Darkz for even greater resonance control and performance enhancement.

Aavik Introducing the Aavik U-X88: Precision, Innovation and Integrated Audio Excellence

Aavik is proud to announce the launch of the Aavik U-x88 range, a groundbreaking collection of all-in one amplifiers featuring the U-188, U-288, and U-588 models. Each model draws inspiration from the acclaimed 880-series flagship models, offering state-of-the-art musical performance in a completely new design. Designed to deliver exceptional musicality, the U-x88 range combines a streamer, DAC, line stage, and power amplifier in a single meticulously engineered enclosure. Each component serves a precisely defined purpose, ensuring the lowest inductance, zero hysteresis, and exceptional resonance control to preserve the finest musical details.

The Exceptional Design Born in Two Exceptional Minds

The Aavik U-x88 series is the result of a unique collaboration between two renowned designers. Gryphon Audio’s esteemed founder, Flemming Erik Rasmussen, joined Aavik’s team in 2021, bringing over 35 years of design expertise. Merging his artistic vision with Michael Børresen’s innovative technical approach, they crafted the U-188, U-288, and U-588 amplifiers to not only look stunning but to deliver an exceptional auditory experience.

Seamless Integration for Enhanced Musical Performance

The U-x88 amplifiers deliver a fully integrated solution, combining essential functions such as streaming, DAC, line stage, and power amplification within a thoughtfully engineered enclosure. This design minimizes signal loss and enhances music reproduction, providing users with a streamlined, high-performance experience.

Advanced Technology for Superior Control

Aavik U-x88 amplifiers are based on the latest version of Pascal class D amplifier technology, which features even faster UMAC switching modulation and generates lesser noise. This circuit now requires lesser filtering and has lower output impedance, which ensures greater control over connected speakers, and consistent performance across the entire musical spectrum.

New High-End Studio and Home Cinema at Poulissen

Poulissen Audio Video Center is pleased to announce the opening of our new high-end listening studio. This space has been carefully designed to offer music lovers and film enthusiasts an unparalleled experience.

High-quality film experience: With a fully integrated 7.2. 4 Sonus faber speaker setup and McIntosh amplifiers, we offer an immersive surround sound experience. The cinema equipment is invisibly integrated into acoustic walls and ceilings for a sleek design.

High-End Audio: Experience a selection of high-end audio equipment from top brands such as Esoteric, Accuphase and McIntosh, presented in an optimized environment for the best listening experience. Or experience high-quality speaker brands such as Bowers & Wilkins, KEF, Monitor Audio or Sonus faber.

Perfect Acoustics: The acoustics of the room have been fully calculated and optimized in collaboration with experts and ensure a balanced and clear sound.

We would like to invite you to visit our new studio and experience the perfect balance between technology, design and sound.

https://www.poulissen.nl/nieuwe-high-end-studio-en-home-cinema-bij-poulissen
