NAGRAから、「 CLASSIC DAC 」登場！！

海外ニュース速報 [World]

Following the successful introduction of the Nagra HD DAC in July 2014, Nagra is at the Venetian suite 30-218 offering a D/A converter in its CLASSIC line. Derived from the HD DAC, and using the exact same digital front end, the new D/A converter will simply be called Nagra CLASSIC DAC. The Nagra HD DAC has been acclaimed the world over as the most “analog” sounding D/A on the market and is considered as a reference. Following the Nagra product strategy – to offer a complete range in two distinct lines both CLASSIC and HD, Nagra is revisiting the HD DAC to create a more affordable alternative to fit in its CLASSIC range, it will be called Nagra CLASSIC DAC.

The Nagra CLASSIC DAC comes in the same chassis as the HD, so it looks very similar. In terms of features it is almost identical though it does not include volume control or a headphone amplifier. The digital input and conversion boards are the exact same as those found in the HD DAC, only the analog stage differs.

Nagra Introduces Their New 24-bit/384kHz / 2x DSD Classic DAC

For the digital section, the CLASSIC DAC features the same digital input board and conversion module as the HD DAC. It makes use of the most advanced conversion techniques available today. The converter comes from a joint-venture with Andreas Koch, AKDesign, pioneer engineer in the DSD (Direct Stream Digital) format, used in professional music studios. The circuits of the Nagra CLASSIC DAC use the DSD 2x version of the format: they operate at a level 128 times superior to that of traditional CD and twice that of SACD. The sampling frequency reaches 5.6 MHz and the internal calculations use 72 bit precision. This method produces a signal with such quality that the steep-slope input filters on the analog section can be eliminated. The result is that the harmonics and transients are perfectly maintained allowing the music to conserve its natural depth and essence. The USB input is Nagra proprietary and can handle signals up to DXD (384kHz/32-bits) and DSD 2x. It is compatible with PC and MAC computers.

On the analog stage: Nagra engineering team worked extensively on a more affordable solution, yet offering striking performance both in terms of measurement and sound perception. As an example, the signal-to-noise ratio of the output stage boasts an impressive 145dB (not weighted)! A number rarely reached by any competitive product at any price level. The output section is based on a class A discrete transistor topology. It includes no less than 9 matched transistors, of military and high-end origins, per channel.

Nagra Introduces Their New 24-bit/384kHz / 2x DSD Classic DAC

The Nagra CLASSIC DAC features a built-in mains power supply that offers excellent performance, but can be further improved by the use of the Nagra MPS full-chassis power supply, though a 12 V DC Lemo connector. The power supply has also been carefully designed and includes no less than 25 dedicated internal power supplies. In typical Nagra way, each stage is carefully decoupled to ensure the best performance. The Nagra CLASSIC DAC will be available in April 2016.

Following the world acclaimed HD DAC considered a reference in D/A conversion, Nagra has worked extensively to provide a more affordable version as part of the CLASSIC range. The new CLASSIC DAC makes use of the exact same digital front-end as the HD DAC (digital input board, USB module and D/A boards). On the output stage the HD DAC’s tube is replaced by a discreet transistor topology, using matched military grade components.

Main Features:
PCM up to 384kHz/24-bits and DSD 2x compatible (384kHz/32-bit)

Two S/PDIF (RCA and BNC), AES/EBU, TOSlink, I2S Nagra digital inputs

Nagra USB input module

RCA and XLR outputs

Built-in mains power supply and Lemo 12 V DC input for improved performance with the Nagra MPS
full chassis power supply.

The Nagra CLASSIC DAC will be available in April 2016.
